sliding doors

Hermetic medical Doors

Our hermetically sealing sliding doors have been specifically designed for use in areas where hygiene and the control of air leakage is critical.

Features

• Offered as automated sliding, hinged swing, x-ray room, or observation room doors.
• these have hermetic seals for applications such as operating theatres, pharmaceutical production, food preparation facilities, and laboratories.
• Hermetic doors help maintain a sterile environment by offering a hermetic seal and are easy to clean.
• This solution can help prevent the spread of germs from one area to another.
• Without this system, a regular closed door will enable the transfer of dust, moisture, and germs to areas that

Description

Composed of the following elements:

• Sliding Operator: Our door mechanism has a brushless DC motor controlled by a 16-bit microprocessor, with a control panel for variation of operating parameters and power supply 100-240V.; includes a drop system for the leaf that allows a progressive vertical and horizontal displacement to ensure the hermetic tightness on closure. Three-position mode selector (manual, open, and auto) integrated into the operator.

• Door Leafs: The door leaf is composed of a set of perimeter profiles in 45mm extruded aluminium, matte anodized finish. 40mm insulating inner core of high- density injected polyurethane PIR (55 Kg/m3) ensures maximum adhesion between elements, giving the door great stability and resistance. Stainless steel or HPL surfaces, easy to clean and suitable for a hospital environment, with high resistance to commonly used chemical products. Metal sealing reducer joint profile fully sealed for easy cleaning.

• Frame: The hollow hermetic frame on one side of the wall / both sides with finishing wall profiles (optional), formed by vertical and horizontal profiles finished in aluminium / stainless steel.

• Sealing: Perimeter sealing gaskets in EPDM provide flexibility and resistance to compression. Direct connection to earth for discharge of static electricity.

• Vision: As an option, we offer a square window 400x400x45 mm (optional). This is double glazed with black glazing spacer, completely sealed, and flush with door surface.

• Hardware: Externally the handles are tubular and are flush internally, both finished in stainless steel, to allow a manual operation of the hermetic door.

• Activation options: Elbow pushbutton, for activation of the door opening. Specially designed for use in operating theatres and clean rooms.

• Safety: Monitored detection and presence radars are fitted internally and externally

All glass revolving door

Reflect, refract, and diffuse light unlike any other. Certainly why our all glass doors are made almost entirely from glass with only stainless steel patch fixings to secure the glass panels together. Compared to a thin edging metal accent frame.

Power assisted drives

First of all the new EA Power Assist Door incorporates the latest design and technology within self parking, energy efficient door drive mechanisms. Even more it is proudly designed and Made in Britain. Therefore reducing the carbon footprint from manufacture to installation.

framed revolving door

To begin, our framed doors are based upon the traditional revolving centre pivoting shaft concept. Accordingly the frames are available as standard or fine frame profiles, the later featuring more glass, therefore affording more reflecting light.

Automatic doors

Oversize or tall, we make beautiful automatic door systems in different styles and surface finishes. Above all, they are expertly installed and reliable by design, thus ensuring our automatic doors compliment the aesthetics of any building.

manual revolving doors

Manual rotating doors are the choice for an elegant and energy efficient entrance solution to any traditional or contemporary style building. Together with options such as speed controllers and heaters, we make featured bespoke doors for all applications.

high capacity revolving door

Designed to be busy, EA two wing high capacity doors demonstrate outstanding operation, performance and functionality. Particularly essential for the energy efficiency and people flow of a bustling building entrance that needs to cope with every scenario.

Benefits of our Hermetic Medical doors

elegant and aesthetic
appearance

Installed in either a concave or convex format. This curved sliding door creates an impressive and enticing entrance meeting the requirements of most architectural styles.

The choice of finishes allow it to match the surroundings or curtain wall and proves to be an elegant and aesthetically appealing entrance solution.

intelligent control

Equipped with Swiss-made Main Control System (MCS) and its proprietary drive and sensor systems. It is fully compliant with EN 16005 standards. Of course an automatic stop function to avoid injury and impact of pedestrians and objects.

The control panel communicates with the MCS bilaterally and from the control panel you can choose the operating mode, set the emergency stop or change operating parameters.
