speed gates
eA Slide Speed Gate
The EA Slide Speed Gate is an elegant, efficient, yet cost effective high Speed Gate entrance solution that improves people flow using any access control technology.
Features
• Fast opening time of just 0.8 seconds
• People flow of up to 30 persons per minute
• Choice of surface finishes
• Robust and reliable design
• Glass or optional plastic retracting panels
• Can be controlled from most access systems
Description
The EA Slide speed gate is distinguished from other types of speed gates & turnstiles by the glass sliding panels and the fact that they can be supplied up to 1.54 metres high. By reducing the risk of people hurdling over them, this design feature ensures a higher level of security when compared to other waist high speed gates & turnstiles.
The turnstile EA Slide speed gate also features a short time of opening/closing time of just 0.8 seconds.
High traffic capacity (30 persons per minute), reliability, space-saving size and stylish appearance makes the EA Slide speed gate the perfect solution for applications where access security is required and is a popular choice for office buildings, business centres and public buildings.
The EA Slide speed gates can be controlled manually or by an access control system. Both access directions are free when the turnstile is powered down
Modes of operation
All of the EA speed gate turnstile range can be controlled in either manual or automatic modes.
manual mode
In the manual mode, the glass panels are opened/closed according to the command from a control panel often positioned at a reception desk or a remote position.
automatic mode
In the automatic mode, the glass panels are opened/closed determined by the signal from an access control system such as a proximity ID card, key fob, biometric reader etc.
Speed Gate Operation Configurations
The Swing Lane speed gate can operate in two ways: either normally closed or normally open. Both access directions either in or out are free to swing open when the turnstile is powered down. (battery backup options are also available)
normally closed
The most common way of configuration, the glass panels are always in the closed position, and only open when the signal to do so is given by the access control.
normally open
The glass panels are always in the open position, and only close when a person is detected entering the turnstile that has not presented an acceptable form of ID to the access control.
